Ateis IDA8 User Manual

Technical Data 551
© 2017, ATEÏS, member of PAX ProAV Group
Rated output power = 125 W (cont. at 40°C)
Two channels bridged = 250 W (cont. at 40°C)
DPA4125:
Rated load resistance = 40 ohm (100 V)
Rated load capacitance = 120 nF (100 V)
Rated output power = 250 W (cont. at 40°C)
Two channels bridged = 500 W (cont. at 40°C)
Frequency response:
40 Hz to 20 kHz(-3 dB)
S/N:
>90 dB (no pilot tone)
Crosstalk:
<70 dB at nominal load for 1 kHz
Distortion:
<0,1% (@ 1 kHz) @ -10dB of rated output power
Environmental
Operating temperature:
-5ºC ~ 55ºC (23 ºF ~ 131 ºF)
Storage temperature:
-40 ºC ~ 70 ºC (-40 ºF ~ 158 ºF)
Relative humidity:
15% to 90%.
Air pressure:
600 to 1100 hPa
Mechanical
Dimensions(W x H x D):
DPA4125/DPA4250: 88.5 x 483 x 370 mm
Weight:
DPA4125 = 14 Kg (31 lb)
DPA4250 = 18 Kg (40 lb)
Colour:
RAL7016
7.4 Console
7.4.1 RU-MAIN/RU-PDC/RU-CTL
Electrical
Voltage
Power Consumption
24 VDC
RU-MAIN
600mA
RU-PDC
200mA
RU-CTL
350mA
Mechanical
Dimensions(H x W x D):
RU-MAIN: 88 x 436 x 150 mm
RU-CTL/RU-PDC: 44 x 436 x 150 mm
Weight:
RU-MAIN: 4.5 kg (10 lbs)
RU-CTL/RU-PDC: 2.5 kg (5.5 lbs)
Colour:
RAL7016
Environmental
Operating temperature:
-5ºC ~ 55ºC (23 ºF ~ 131 ºF)
Storage temperature:
-40 ºC ~ 70 ºC (-40 ºF ~ 158 ºF)
Relative humidity:
15% to 90%.
Air pressure:
600 to 1100 hPa
7.4.2 DialPad
Mechanical
Dimensions(L x W x H):
255mm x 108mm x 66mm
Telephone Keypad:
Touch key (0~9 , #, * )
Support resembles telephone keypad
Panel Display:
128*32 Pixels
Monochrome (White)
Buzzer:
Sound pressure level >85dBA@10cm
Status LED:
Blue
ø 3mm
Display the status of button
RS485 Protocol:
RJ45 @Maximum Distance 500M(between system unit and
