IDA8 Global-Net User Manual504
© 2017, ATEÏS, member of PAX ProAV Group
Digit Keys: 16 digit keys includes the numbers from "0" to "9", symbols "*" and "#", letters from "A"
to "D".
Current Number: Record the numbers which are dialed or displayed the incoming calls.
Back: Erase the last digit of current Number.
Note: A long press by pressing and holding the [BACK] button will delete all the dial numbers.
Last Number: Display the number of last call.
Redial: Redial the last number.
Dialing: The status of telephone card is dialing.
Ringing: An incoming call needs to be received.
Set: Light up if the external telephone set doesn't connect to the telephone card.
Ready: Light up when the telephone line and CAT5 cable connection are connected to the system
unit.
Connect: Light up after a few seconds of the dialing call.
Busy: Light up if the telephone remote is in busy status and is not allowed to receive any other
calls.
MCU: Function Reserved.
Fault: Light up if there is an error on telephone line.
Mute: Mute the transmitting audio.
Flash: Allow a 3-way telephone conversation. Press this button during the conversation of the first
remote phone, and dial the number of the second remote telephone. Once the second remote
accepts the call, press [FLASH] button again and start a 3-way telephone conversation.
Level: Adjust the level of transmitting audio.
Delay Key Define: Define the key for delay time. For some telephone systems, it will needs to dial
0 for an outside line before dialing the required number. Between 0 and the outside phone
number, it requires a short delay. In this case, you can define and select the digit signal included ''
A,B,C,D,*,# '' and delay time(sec) for your preference. For example, the digit signal you select is '' #
'', the dial numbers should be "0#XXXXXXXXXX" where X is the outside phone number you want
to call.
Delay Time: Select the delay time for a delay digit.
5.25.2 TC Receive
Receive a telephone call and detects if a DTMF tone output logic signal responded to the key pressing
on remote telephone. It needs to work with the telephone card.
