Ateis IDA8 User Manual

Technical Data 553
© 2017, ATEÏS, member of PAX ProAV Group
Audio Characteristics
Sensitivity range
(60~130dBA), ±5 dBA
THD:
<0.2%
Equivalent:
-80 dBu 50~16 kHz@600Ω
THD+N @ dBu:
0.2% 50~16 kHz
Frequency response:
10 + 1 dBu 50~16 kHz@0 dBu, sample rate= 48 k
Sampling rate:
48 kHz only 1 selection
*The di erence between 1kHz and the frequency of maximum value
Mechanical & Environmental
Dimensions:
Hexagonal cylinder: 100mm(Φ ) x 130mm(H)
Weight:
0.13 Kg
Operating temperature:
0ºC ~ 55ºC
Storage temperature:
-40° to +80° C
7.4.5 PPM-AS
Electrical
Item
Voltage
Current Consumption
Comment
DC Input
18V~26V, Typical 24V
120mA
-
Microphone
Microphone level:
6dBu
Output Impedance:
100Ohm
THD:
@ 1kHz < 1%
Bandwidth:
@ -3dB = 100Hz ~ 18kHz
Front Panel Loudspeaker
Impedance:
4Ohm
Maximum Power:
@ 1kHz = 1W
THD:
@ 1kHz < 1%
Bandwidth:
@ -3dB = 200Hz ~ 8kHz
Mechanical
Dimensions( W x L x H):
105mm x 190mm x 50mm
Cable Length:
100m(control and power on the same cable)
900m(when power line connects to junction box).
Weight:
4.7 kg (10.4 lbs)
Color:
RAL7035
Operating temperature:
0ºC ~ 55ºC
Comes standard with Junction box (JB) and CAT5 cable (1.5)
7.4.6 PSS-AS
Electrical
Item
Voltage
Current Consumption
Comment
DC Input
18V~26V, Typical 24V
250mA
-
Microphone
Microphone level:
6dBu
Output Impedance:
100Ohm
THD:
@ 1kHz < 1%
Bandwidth:
@ -3dB = 100Hz ~ 18kHz
Noise Gate Threshold:
-84dBu ~ -24dBu
Max Output Level:
-54dBu ~ 35dBu
Attack Time:
8ms
Release Time:
100ms
Front Panel Loudspeaker
