Table 4.11—IFPSMC Box Connector 0 User Signals Available
Pin
Number
Signal
IFPS Model
IFPSMC-1 IFPSMC-2 IFPSMC-3 IFPSMC-4 IFPSMC-5 IFPSMC-6
35 D GND Available Available Available Available Available Available
36 D GND Available Available Available Available Available Available
37 P2.0 Available Available Available Available Available Available
38 P1.7 Available Available Available Available Available Available
39 P2.7 Available Available Available Available Available Available
40 P2.5 Available Available Available Available Available Available
41 P1.4 Available Available Available Available Available Available
42 P1.3 Available Available Available Available Available Available
43 P1.2 Available Available Available Available Available Available
44 D GND Available Available Available Available Available Available
45 P2.2 Available Available Available Available Available Available
46 P2.3 Available Available Available Available Available Available
47 P0.3 Available Available Available Available Available Available
48 P0.7 Available Available Available Available Available Available
49 P0.2 Available Available Available Available Available Available
50
D GND Available Available Available Available Available Available
51 P0.5 Available Available Available Available Available Available
52 P0.0 Available Available Available Available Available Available
53 D GND Available Available Available Available Available Available
54 AO GND Available Available Available Available Available Available
55 AO GND Available Available Available Available Available Available
56 AI GND
57 AI 7 Available(+) Available(+) Available(+) Available(+) Available(+) TC1-SG3(+)
58 AI 14 Available(-) Available(-) Available(-) Available(-) Available(-) TC1-SG2(-)
59 AI GND
60 AI 5 Available(+) Available(+) Available(+) Available(+) Available(+) TC1-SG1(+)
61 AI 12 Available(-) Available(-) Available(-) Available(-) Available(-) TC1-SG0(-)
62 AI SENSE1
63 AI 11 Available(-) Available(-) Available(-) Available(-) Available(-) Available(-)
64 AI GND
65 AI 2 Available(+) Available(+) Available(+) Available(+) Available(+) Available(+)
66 AI 9 Available(-) Available(-) Available(-) Available(-) Available(-) Available(-)
67 AI GND
68 AI 0 Available(+) Available(+) Available(+) Available(+) Available(+) Available(+)
Notes:
1. TC-SGx(x) = Transducer Connection number - Signal (SGx) - positive (+) or negative (-) input
2. Available (x) = User signal available - positive (+) or negative (-) input
