Table 11.2—XML Elements in netftapi2.xml
XML Element Data Type Description Reference
setmce USINT Threshold processing status
moncon
mce USINT[16] Threshold statemens’ individual enabling
mcx USINT[16] Threshold statements’ selected axes
mcc USINT[16] Threshold statements’ comparisons
mcv DINT[16] Threshold staements’ counts values for comparison
mco HEX8[16] Threshold statements’ output codes
cfgcalsel USINT Calibrationusedbyactiveconguration
cong
cfgcalsn STRING8 Serialnumberofactiveconguration’scalibration
cfgfu USINT Forceunitsusedbyactiveconguration
scfgfu STRING8 Nameofforceunitsusedbyactiveconguration
cfgtu USINT Torqueunitsusedbyactiveconguration
scfgtu STRING8 Nameoftorqueunitsusedbyactiveconguration
cfgtdu USINT
Tool transformation distance units that are used by an active
conguration.
scfgtdu STRING16
Name of tool transformation distance units that are used by
anactiveconguration.
cfgtau USINT
Tool transformation rotation units that are used by an active
conguration.
scfgtau STRING8
Name of tool tranformation rotation units that are used by an
activeconguration.
cfgtfx REAL[6]
Tool transformation distances and rotations that are applied
byactiveconguration.
comnetdhcp ENABL DHCP behavior setting
comm
comnetip STRING15 Static IP address
comnetmsk STRING15 Static IP subnet mask
comnetgw STRING15 Static IP gateway
nethwaddr STRING17 Ethernet MAC address
commrdtrate UDINT RDT output rate
comrdtbsiz USINT RDT Buffer Mode buffer size
mfgdighwa STRING17 Ethernet MAC Address
manuf
mfgdigsn STRING8 Digital board serial number
mfgdigver STRING8 Digitalboardrmwarerevision
mfgdigrev STRING8 Digital board hardware revision
mfgtxdmdl STRING16 Analog board location
manuf
netip STRING15 IP address in use
runrate UDINT Internal sample rate for strain gage collection –
To Next Page
