F/T DAQ Installation and Operation Manual
Document #9610-05-1017-06
ATI Industrial Automation, 1031 Goodworth Drive, Apex, NC 27539 USA +1-919-772-0115 www.ati-ia.com
26
5.2 Electrical Specifications
5.2.1 PS and IFPS box with transducer attached.
Signal Minimum Typical Maximum Units
+5V Power Input Voltage 4.75 5.00 9.00 V DC
+5V Power Input Current 260 mA
+5V Power Input Noise 75 mV p-p
+5V Power Input Regulation 0.5%
Table 5.2—PS and IFPS box with transducer attached
5.2.2 Transducer with Onboard Interface Board
Signal Minimum Typical Maximum Units
+V
ANA
Power Input Voltage 13.00 15.00 17.00 V DC
-V
ANA
Power Input Voltage -17.00 -15.00 -13.00 V DC
+V
ANA
Power Input Current 16 mA
AGnd Power Input Current 25 mA
-V
ANA
Power Input Current -41 mA
V
ANA
Power Input Noise 75 mV p-p
V
ANA
Power Input Regulation 0.5%
Table 5.3—Transducer with Onboard Interface Board
5.2.3 Transducer Output Signals
These are output by the transducer and passed through the PS box or are output by the IFPS
box.
Signal Minimum Maximum Units
SGx output* -V
ANA
+0.6 +V
ANA
–0.8 V
SGx reference AGnd AGnd V
SGx output, over 10V calibrated range -10 +10 V
SGx output, over 5V calibrated range -5 +5 V
* These output levels only occur if the transducer is loaded significantly past its calibration
range.
Table 5.4—Transducer Output Signals
The transducer outputs are designed to work with a differential input to the DAQ system for
best performance.
The calibrated output voltage range is indicated as a suffix to the calibration. For example, a
GAMMA transducer with SI-65-5 calibration and a +10V output voltage range would be
expressed as a GAMMA/SI-65-5:10V. The output voltage range can also be read using the
OutputRange property of the ATIDAQFT software component.
5.3 Transducer Signals
This section covers the connections for transducers with on-board electronics (9105-TIF part
numbers). These transducers have a 20-pin connector. User connections to transducers
without on-board electronics (9105-TW part numbers) are not supported and therefore not
covered in this document.
