7.3.17 Omega160 (US Calibration)
0
200
400
600
800
1000
1200
0 500 1000 1500 2000 2500 3000 3500 4000
Tz (in-lb)
Fxy (lb)
0
500
1000
1500
2000
2500
3000
0 500 1000 1500 2000 2500 3000 3500 4000
Txy (in-lb)
Fz (lb)
Omega160 US-600-3600 Omega160 US-300-1800 Omega160 US-200-1000
