ATI Technologies DAQ F - Mini45 (si Calibration)

F/T DAQ Installation and Operation Manual
Document #9610-05-1017-06
ATI Industrial Automation, 1031 Goodworth Drive, Apex, NC 27539 USA +1-919-772-0115 www.ati-ia.com
55
7.3.10 Mini45 (SI Calibration)
0
200
400
600
800
1000
1200
1400
1600
0 5 10 15 20 25 30 35 40
Tz (Nm)
Fxy (N)
0
500
1000
1500
2000
2500
3000
3500
4000
0 5 10 15 20 25 30 35
Txy (Nm)
Fz (N)
Mini45 SI-580-20 Mini45 SI-290-10 Mini45-SI-145-5
