F/T DAQ Installation and Operation Manual
Document #9610-05-1017-06
ATI Industrial Automation, 1031 Goodworth Drive, Apex, NC 27539 USA +1-919-772-0115 www.ati-ia.com
41
7.2.7 Delta
English (US) Metric (SI)
Calibration US-50-150 US-75-300 US-150-600 SI-165-15 SI-330-30 SI-660-60
Rated Sensing Ranges
Fx, Fy ±50 lb ±75 lb ±150 lb ±165 N ±330 N ±660 N
Fz ±150 lb ±225 lb ±450 lb ±495 N ±990 N ±1980 N
Tx, Ty, Tz ±150 in-lb ±300 in-lb ±600 in-lb ±15 Nm ±30 Nm ±60 Nm
Resolution*
Fx, Fy 1/512 lb 1/256 lb 1/128 lb 1/128 N 1/64 N 1/32 N
Fz 1/256 lb 1/128 lb 1/64 lb 1/64 N 1/32 N 1/16 N
Tx, Ty 3/512 in-lb 3/256 in-lb 3/128 in-lb 1/2112 Nm 3/3200 Nm 3/1600 Nm
Tz 1/256 in-lb 1/128 in-lb 1/64 in-lb 1/2112 Nm 3/3200 Nm 3/1600 Nm
Physical Properties US Metric
Stiffness (Calculated)
X-axis and Y-axis force (Kx, Ky)
210×10
3
lb/in 37×10
6
N/m
Z-axis force (Kz)
350×10
3
lb/in 61×10
6
N/m
X-axis and Y-axis torque (Ktx, Kty)
460×10
3
in-lb/rad 52×10
3
Nm/rad
Z-axis torque (Ktz)
830×10
3
in-lb/rad 94×10
3
Nm/rad
Resonant Frequency (Measured)
Fx, Fy, Tz 1.5 kHz
Fz, Tx, Ty 1.7 kHz
Maximum Single-axis Load
Fx, Fy ±770 lb ±3400 N
Fz ±2600 lb ±12,000 N
Tx, Ty, ±2000 in-lb ±220 Nm
Tz ±3700 in-lb ±420 Nm
Weight
Transducer with standard plates 2.0 lb 910 g
Transducer with ring/plug TAP 2.6 lb 1152 g
Transducer with ring/plug MAP 2.7 lb 1236 g
Material
Transducer R
c
32 Stainless Steel
Standard mounting adaptor Aircraft Aluminum
*Resolutions are typical for a 16-bit data acquisition system.
