7.3.16 Theta (SI Calibration)
0
500
1000
1500
2000
2500
3000
3500
4000
4500
5000
0 50 100 150 200 250 300 350 400 450 500
Tz (Nm)
Fxy (N)
0
2000
4000
6000
8000
10000
12000
14000
0 50 100 150 200 250 300 350 400 450
Txy (Nm)
Fz (N)
Theta SI-2500-400 Theta SI-1500-240 Theta SI-1000-120
