F/T DAQ Installation and Operation Manual
Document #9610-05-1017-06
ATI Industrial Automation, 1031 Goodworth Drive, Apex, NC 27539 USA +1-919-772-0115 www.ati-ia.com
27
The transducer connector mates to a Hirose HR25-9TP-20S connector. Wire colors are
shown for use with 9105-C-H-U cable assemblies.
Note: Multi-colored wires are identified as follows: The first color listed is the
predominant color of the wire and the second color is the stripe on the wire.
Pin Description Wire Colors Pin Description Wire Colors
1 SG0 output Brown 11 -V
ANA
power input Red/White
2 Reserved Orange 12 SG1 reference Yellow/White
3 SG0 reference Brown/White 13 SG4 output Violet
4 SG3 reference Blue/White 14 Reserved White
5 SG5 reference Grey/White 15 Reserved Black/White
6 +V
ANA
power input Red 16 Reserved Orange/White
7 SG1 output Yellow 17 SG2 output Green
8 SG3 output Blue 18 SG4 reference Violet/White
9 SG5 output Grey 19 Reserved White/Black
10 AGnd power input Black 20 SG2 reference Green/White
Shell Shielding Shield
Table 5.5—Transducer connector connections and 9105-C-H-U cable wire colors
5.4 PS and IFPS Signals
5.4.1 PS 20-pin Circular Connector
These signals and pin numbering are the same as the transducer signals listed in Section 5.3.
See Table 5.5.
5.4.2 PS and IFPS 26-pin High Density D-Subminiature Connector
This connector mates to an industry standard female 26-pin high-density D-subminiature
connector with screw locks. Wire colors are shown for use with 9105-C-PS-U cable
assemblies.
Pin Description Wire Colors Pin Description Wire Colors
1 Reserved Orange 11 0V power input Red/White
2 +5V power input Red 12 Reserved White/Black
3 Reserved White 13 SG5 reference Grey/White
4 SG5 output Grey 14 SG4 reference Violet/White
5 SG4 output Violet 15 SG3 reference Blue/White
6 SG3 output Blue 16 SG2 reference Green/White
7 SG2 output Green 17 SG1 reference Yellow/White
8 SG1 output Yellow 18 SG0 reference Brown/White
9 SG0 output Brown 19 Reserved Black/White
10 Reserved Orange/White 22 AIGnd Black
Shell Shielding Shield
Table 5.6—PS box and IFPS box connector connections and 9105-C-PS-U cable wire colors
