ATI Technologies DAQ F User Manual

F/T DAQ Installation and Operation Manual
Document #9610-05-1017-06
ATI Industrial Automation, 1031 Goodworth Drive, Apex, NC 27539 USA +1-919-772-0115 www.ati-ia.com
48
7.3.3 Nano25 (US Calibration)
0
10
20
30
40
50
60
70
80
90
0 102030405060
Tz
(
in-lb
)
Fxy (lb)
Note: Applying moments beyond +
30 in-lb (+3.4Nm) in Tz can cause hysteresis and permanent zero-
point change in this transducer
0
50
100
150
200
250
300
350
0 1020304050607080
Txy (in-lb)
Fz (lb)
Nano25 US-50-50 Nano25 US-25-25
