ATI Model F12/D Gas Transmitter Part 4 – Operation
38
O&M Manual (Rev-H)
4.7 Sensor Menus, Methods, and Settings
Sensor Menu
Figure 42. Sensor Menu.
Sensor Settings Menu
The transmitter accommodates a variety of sensors that automatically configure the transmitter with the
gas name, range, units, and other settings, and contain calibration data to convert the sensor analog
output to a gas concentration reading. Some of these settings can be changed by the transmitter and it is
important to make sure they are configured properly for the site.
Figure 43. Sensor Settings Menu
Sensor Model Menu
Figure 44. Sensor Model Menu
Configure the sensor range, damping, and blanking (see
Sensor Settings, below).
Maintain the accuracy of the gas sensor (see Sensor Calibration on
page 40)
Configure automatic gas sensor tests or perform manual tests
(see Sensor Auto-test on page 44).
Displays the model name. Select to view sensor specific
settings or information about the installed sensor (below).
Displays the name of the target gas (read only).
Select to view and adjust the sensor’s upper range, blanking,
and damping settings (below)
Sensor model name (read only)
Sensor upper range limits (read only)
