ATI Model F12/D Gas Transmitter Part 4 – Operation
59
O&M Manual (Rev-H)
4.9 Data-log Menus, Methods, and Settings
The transmitter records gas concentrations in one of 12 intervals ranging from 1 to 60 minutes, providing
data from 11 to 474 days. Table 4 details the sampling intervals, and the samples/day and totals days for
each interval.
Table 4. Data-log sampling metrics
The gas concentration reading is recorded as an instantaneous value and is not averaged or filtered in
any way. When the data log memory is filled, new records overwrite older ones.
Data Log Menu
The Data Log Menu permits access to configuration, review, and print menus.
Figure 74. Data Log Menu
Configure the data log settings (see Data Log Setup Menu below).
View the logged data as a graph or single text records.
Send a tabular ASCII report to the device connected to the COM
port (see Data Log Print on the next page). Note: only available on
transmitters with an RS232 or RS485 interface. The data log must
not be empty, and the COM protocol must be set to ASCII.
Otherwise, the transmitter will display an exception message.
To Next Page
