ATI Model F12/D Gas Transmitter Part 4 – Operation
77
O&M Manual (Rev-H)
4.12 System Menu
Figure 104. System Menu
Clock Menu
The Clock Menu is used to set the transmitter’s real-time clock, which is recorded during sensor
calibration and data logging, and is used to trigger Auto-test starts
Figure 105. Clock Menu
Reset Menu
Figure 106. Reset Menu
Set or update the transmitter’s real-time-clock.
Restart the transmitter or change all user settings to default
values.
Display transmitter and sensor version information.
Change the site name displayed during startup review.
Change the day of the week: Monday, Tuesday, Wednesday,
Thursday, Friday, Saturday, and Sunday
Configure the month, date, and year, in the format specified by
the Format setting (below). Built-in support for leap year.
Note: you may select and adjust the year separately.
Change the date format:
MM/DD/YYYY, example: 09/14/2014
DDMMM/YYYY, example: 09Sep/2014
Change the time of day (24-hour format, 00:00 to 23:59)
Restart the transmitter without cycling power.
Reset all user settings to default values.
NOTE: this method is provided to recover from a corrupted user
memory. It does not affect calibration of the sensor or
transmitter analog inputs or outputs. After running this
method, you will be required to manually restore all of the
transmitter alarm, data logger, i/o (communications, relays, and
4-20mA), panel (display and security), settings, as well as the
transmitter’s real-time clock.
>Menu >Setup >System >Clock
