Atlas Copco FlexiROC T35 R User Manual

FlexiROC T35 R/T40 R 5 Controls
61 No: 3171473547.1 en
Sensor Function Status Event
~8200 mV Aim device straight
ahead
Aim device max left
PLC/Y105 Reset hole length 0-10000 mV When zeroing
B172 Length meter pulses A/B When measuring
Table31: Sensor information
Sensor Function Status Event
S139 Key in ignition position 1 Percussion active
B360 Air filter, engine 0 Filter OK
B365 Air filter, compressor 0 Filter OK
S180 Compressor on 1 Compressor loaded
B381 ECL collection, low
pressure
1 Pressure OK
B382 ECL collection, high
pressure
1 Pressure OK
B143 Hydraulic oil level low 1 Oil level OK
S132 Emergency Stop Activ-
ated
1 Emergency stop not
triggered
Table32: Sensor information
Sensor Function Status Event
PLC/Y20 Percussion ON 1 Percussion ON
PLC/Y50 Pause signal/unthread-
ing
1 Signal from sensor re-
garding pause
S130 Remote panel in drilling
position
1
S119/A1 Upper drill-steel sup-
ports open
1 Drill-steel support is
open
S119/A3 Upper drill-steel sup-
ports closed
1 Drill-steel support is
closed
B316 Laser sensor activated 1 Sensor has received
laser signal
A59 Remote panel activated 1 Remote control box act-
ive
B104 Cradle in calibration
mode
1 Cradle is in calibration
position
Table33: Sensor information
