Atlas Copco FlexiROC T35 R User Manual

FlexiROC T35 R/T40 R 5 Controls
62 No: 3171473547.1 en
Sensor Function Status Event
K200 Stop Engine 0 Engine stopped
PLC/X4 Drill stop/hole length
reached
1 Desired hole length ob-
tained
Table34: Sensor information
!
NOTE: Any status other than the one given indicates a sensor fault or that something
else happened to the function.
6.3 ECM information
ECM information.
Graphic presentation for list of sensors connected to ECM (Engine Control Module). The
list shows position designation, description and whether or not current status is OK.
In the event of a sensor fault the sensor in question and fault type are shown in the menu.
7 Settings
Settings.
