Method 2:
ConnectalldevicestoEthernetandcontrolthembytheirownIPaddress.Theadvantage
ofthismethodis:youcanseetheVUmetersofallconnecteddevices.Thedisadvantage
ofthismethodis:everydeviceneedshisownEthernetconnectionandIPaddress.
ToconfigureyoursystemaccordingtoMethod2,proceedwiththefollowingprocedure:
1) ConnectthefirstdeviceofyoursetuptoyourEthernetnetwork
2) Settheaddressofthefirstdeviceto“M001”,thiscanbedoneinthe“Setup” 
 menu,under“AddressSettings”.
3) ChangetheIPaddressofthefirstdevicetoonewhichisavailableinyour
 Ethernetnetwork(Forexample192.168.0.191).Thiscanbedoneinthe“Setup”
 menu,under“NetworkSettings”.
4) DisconnectthefirstdeviceofyoursetupfromtheEthernetnetwork
5) ConnecttheseconddeviceofyoursetuptoyourEthernetnetwork
6) Settheaddressfortheseconddeviceto“M002”,thiscanbedoneinthe“Setup”
 menu,under“AddressSettings”.
7) ChangetheIPaddressoftheseconddevicetoonewhichisavailableinyour
 ethernetnetwork(Forexample192.168.0.192).Thiscanbedoneinthe“Setup”
 menu,under“NetworkSettings”.MakesurethisIPaddressisdifferentfromthe
 firstdevice’sIPaddress.
8) DisconnecttheseconddeviceofyoursetupfromtheEthernetnetwork
9) GiveallthedevicesinyoursetupanuniquebusandIPaddress.Thiscanbedone
 byrepeatingstep5to8ofthisprocedure.Makesureeverydevicehasaunique
 busandIPaddress.
10) Now,alldeviceshaveauniquebusandIPaddress,andnodeviceisconnected
 totheEthernetnetwork.
11) ConnectalldevicestoyourEthernetnetwork
12) Connectthedeviceswitheachotherthroughfiberconductors,usingtheloop
 principleasshowninFigure1.
13) Restartalldevices
14) Alldevicesshoulddisplaynow“FiberOK”ontopoftheirmainpage,nexttothe
 connectionstatus.

AUDAC M2 Specifications

General

Monitor out	1
Number of Euroblock input connectors	20
Number of Euroblock output connectors	24
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
DJ mixer	No
Rack capacity	19U
Rack mounting	Yes
Channels quantity	- channels
Digital sound processing	- bit
Equalizer bands quantity	5

Weight and Dimensions

Depth	350 mm
Width	482 mm
Height	132 mm
Weight	8850 g
