Volume
Usingthe‘Volume’dropdownlist,thedesiredvolumeuponsceneactivationcanbe
selectedforthecorrespondingoutput.Thestandardvalueissetto‘Don’tchange’
meaningthevolumeforthecorrespondingoutputwon’tchangeuponsceneactivation.
Whenthedesiredvolumehasbeenselected,thevolumeforthecorrespondingoutputwill
changeaccordinglyuponsceneactivation.
Trigger
Usingthe‘Trigger’dropdownlist,theconditionunderwhichthis‘Globalscene’should
berecalledcanbeselected.Thislistboxcontainsalltheavailableinputssuchascontact
inputsandaudioinputs.Whenacontactinputisselected,thescenewillberecalledwhen
aconnectionhasbeenmadebetweentheselectedtriggercontact.Incaseanaudioinput
hasbeenselected,thescenewillberecalledatthepresenceofanaudiosignalonthe
selectedinput.
Scene names
Customnamescanbeassignedtotheglobalscenes,tokeepaclearoverviewofall
thefunctions.Namessuchas‘BackgroundMusic’,‘Party,‘Presentation’,‘Evacuation’
cangiveaclearoverviewoftheselectedpresets.Tochangethescenenames,clickthe
‘Changenames’buttononthebottomofthewindow.Apopupwillappear,containingall
thescenenameswhichcanbemodifiedbysimplyusingthebackspacekeyandtyping
thedesiredname.Afterthescenenamesareentered,clickthe‘Change’buttonandthe
nameswillbechangedaccordingly.
Save
AfterallsettingsfortheGlobalscenehavebeenmade,clickthe‘ChangeGlobalScene’
buttononthebottomofthewindowandallsettingsfortheselectedscenewillbesaved.
Settings >> Timer Settings
The‘TimerSettings’windowprovidesthepossibilityforprogrammingupto256timer
scheduledactions.ActionssuchasChangerouting&volume,Enable/Disablemute,Set
Pagingvolume,SwitchRelayOn/OffandPlayvoicesfilecanbeprogrammed.
M2 Timer settings

AUDAC M2 Specifications

General

Monitor out	1
Number of Euroblock input connectors	20
Number of Euroblock output connectors	24
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
DJ mixer	No
Rack capacity	19U
Rack mounting	Yes
Channels quantity	- channels
Digital sound processing	- bit
Equalizer bands quantity	5

Weight and Dimensions

Depth	350 mm
Width	482 mm
Height	132 mm
Weight	8850 g
