Ifyouloginusingtheadministratorpassword,yougetaccesstoallfunctionsand
configurationoptionsoftheM2Mixer(Thefactorydefaultpasswordforadministrator
accessis‘M2’).
Whenyouloginusingtheuser password,youonlygetaccesstothebasicfunctions
oftheM2mixer,suchaschangingthevolumeandchangingthemixingforaparticular
outputzone.(Thefactorydefaultpasswordforuseraccessis‘user’).
Aftertherightpasswordisentered,clickthe‘OK’button,andyouwillberedirectedtothe
mainscreenoftheM2interface.
NOTE
ThepasswordscanbechangedintheSettings>>Systemconfiguration>>Password
settingsmenu(Onlyadministrator)
Main screen
Themainscreengivesanoverviewofalltheoutputs,withavolumecontrolfader,amute
buttonandaninputselectiondropdownlistforeveryzone.Atadministatorlevel,some
additionalfeaturesareprovidedsuchasa‘Settings’buttonforeveryoutputtoproceed
tothatoutput’soutputsettingswindowanda‘Setup’buttontoproceedtothegeneral
settingsmenu.
M2 Main screen (Administrator level)
Volume control
Thevolumeofeachoutputchannelcanbesetbymovingthefaderofthecorresponding
channelupordown.Atthetopandbottomsideofeachfaderisabuttonwithanarrow
displayedwherebythevolumecanberaisedorloweredinstepsof1dB.Atthebottomis
a‘Mute’buttonprovidedwhichmutesthevolumeofthecorrespondingoutputchannelin
oneclick.WhenthevolumeismutedthebuttonwillturnRed.Tounmute,justpressthe
buttonagain.

AUDAC M2 Specifications

General

Monitor out	1
Number of Euroblock input connectors	20
Number of Euroblock output connectors	24
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
DJ mixer	No
Rack capacity	19U
Rack mounting	Yes
Channels quantity	- channels
Digital sound processing	- bit
Equalizer bands quantity	5

Weight and Dimensions

Depth	350 mm
Width	482 mm
Height	132 mm
Weight	8850 g
