Chapter 6
Paging
1 Function paging example
ThemostbasicpagingsetupexampleisanM2withaAPM101pagingconsoleconnected
toit.Inthiscasetheannouncementswillbeheardononeormoreoutputs,asdefinedin
thepagingconfigurationsetup.
M2
One function paging example
8 Function paging example
AnotherpossiblepagingsetupisanM2withaAPM108pagingconsoleconnectedtoit.
Thedifferencebetweenthepreviousexampleisthatthefunctionforeachbuttoncan
beseparatelydefinedinthepagingconfigurationsetup.TheAPM108pagingconsole
contains8zoneselectionbuttons,whichmakeitpossibletomakeannouncementsto
everyoutputseparately,ortomultipleoutputssimultaneously.Thefunctionsforeach
buttoncanbedefinedusingthepagingconfigurationsetup.
M2
Eight function paging example
Priority
Pagingisalwaysprioritybased.WhenmultipleAPMpagingconsolesareconnectedto
oneM2system,andmultipleAPM’swanttomakeanannouncementsimultaneously,the
prioritysettingswilldeterminewhichmessagewillbeheard.
TheprioritylevelisrelatedtotheaddressofeachAPMconsole,whichisunique.The
APMwiththelowestaddresshasthehighestpriority.Thismeans,whentwoAPM’sare
connectedandAPMwithaddress“002”isannouncingamessage,whileatthesame
timeAPMwithaddress“001”wantstoannounceamessage,themessagefromAPM
“002”willbeinterrupted,andthemessagefromAPM“001”willbeannounced.

ForvoicefilesandmessageswhicharestoredinsidetheAPMmemory,thepriorityworks
different.Aprioritynumbercanbeassignedtoeachstoredmessage,makingitpossible
togiveemergencymessagesahigherpriority.
