AUDAC M2 User Manual

17
3) Connecting wall panels
ConnecttheDW3020/4020andDW5065wallpanelstothePI(PeripheralInterface)inputs
(RJ45connectors)onthebacksideoftheM2.AllPIports(1to10)supportdatatransfer,
whileonlythe8firstPIports(1to8)supportdata+digitalaudiotransfer.Becauseofthis,
thebasicDW3020/4020wallpanelsmaybeconnectedtoallPIportswhiletheAll-In-
OneDW5065wallpanelsmayonlybeconnectedtoPIports1to8.
MultipleDW3020/4020wallpanelscanbeconnectedtoonesinglePIinputusingbus
cabling(connectingallthewallpanelsinparallel)oreachwallpanelcanbeconnected
usingaseparatecabletoaseparateport.Itdoesnotmatterwhichinputisusedforwhich
zone,thesettingsforwhichwallpanelshouldcontrolwhichzonecanbemadeinthe
settingsmenu.
OnlyoneDW5065All-In-Onewallpanel(withaudioinput)maybeconnected
simultaneouslytoaPIinputport(1to8).
4) Connecting a computer
AcomputercanbeconnectedtotheM2throughEthernet.Ifthecomputerisdirectly
connectedtotheM2,acrossednetworkcableisnecessary.IftheM2isconnectedto
alocalLANnetwork(connectedtoarouter/switch/hub)astraightnetworkcableis
necessary.AskyourITadministratorforhelp.
Togetaccesstotheuserinterface,enterthefollowingaddressinyourinternetbrowser
addressbar:‘http://192.168.0.190’(ThisisthefactorydefaultIPaddressoftheM2,can
bechangedinthesettingsmenu).Thedefaultadministratorpassword(givesyouaccess
toallfunctions)is‘M2’andthedefaultuserpassword(givesyouonlyaccesstothebasic
functions)is‘user’.Ifanychangestothesettingsshouldbemade,theadministrator
passwordshouldbeused.
Configuring the M2
1) Changing the IP address
YoucanskipthisstepwhenthedefaultIPaddress‘192.168.0.190’isnotinuseby
anotherdeviceinyournetwork,andisOKforyou.IfyouliketochangetheIPaddress,
gotothe‘Setup’menu(clicktheiconintheupperrightcornerofthemainscreen)click
on‘Systemconfiguration’andgoto‘NetworkSettings’.NowyoucanchangetheIP
address,andclick‘OK’toapplythechangesandsave.Afterwards,yourbrowserwillbe
automaticallyredirectedtothenewIPaddressoftheM2,andthedefaultIPaddressisno
longervalid.
2) Changing the password
Youcanskipthisstepifthedefaultpassword‘M2’foradministratorand‘user’forusers
isOKforyou,butwealwaysrecommendtochangethesepasswords,especiallywhen
yourM2isconnectedtoapublicnetworkwhereexternalusershaveaccess.Ifyouliketo
changethepassword,gotothe‘Setup’menu,clickon‘Systemconfiguration’andgoto
‘Passwordsettings’.Hereyoucanchangethepasswords.First,theoldpasswordneeds
tobeentered,andsubsequentlythenewpasswordneedstobeenteredtwice(Max8
characters).Pressthe‘OK’buttontosavethenewpassword.Now,youalwaysneedtolog
inwiththenewpassword.Thedefaultpasswordisnolongervalid.

AUDAC M2 Specifications

General

Monitor out	1
Number of Euroblock input connectors	20
Number of Euroblock output connectors	24
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
DJ mixer	No
Rack capacity	19U
Rack mounting	Yes
Channels quantity	- channels
Digital sound processing	- bit
Equalizer bands quantity	5

Weight and Dimensions

Depth	350 mm
Width	482 mm
Height	132 mm
Weight	8850 g
