AUDAC M2 User Manual

19
CertainactionssuchasVolumeChange,Inputchange,Mute,Tonecontrolandsettings
canbedisabledfromthewallpanelandthephantompoweronthemicrophoneinputcan
beenabledbyclickingthecheckboxes.
Finally,thedisplaybacklightlevelandscreensaversettingscanbeadjusted.
Afterallsettingsaredone,clickthe‘SavetoWallpanel’buttonandallyoursettingswill
besendtotheselectedDW5065wallpanel.Repeatthisactionforalltheconnected
DW5065WallPanels.
Ready
Yoursystemisnowcompletelyconfiguredandreadytobeused.

AUDAC M2 Specifications

General

Monitor out	1
Number of Euroblock input connectors	20
Number of Euroblock output connectors	24
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
DJ mixer	No
Rack capacity	19U
Rack mounting	Yes
Channels quantity	- channels
Digital sound processing	- bit
Equalizer bands quantity	5

Weight and Dimensions

Depth	350 mm
Width	482 mm
Height	132 mm
Weight	8850 g
