AUDAC M2 User Manual

11

RS232 / RS485 / TCP/IP
TheM2hasRS232,RS485andTCP/IPportswhichallacceptthesamecommands.The
completecommandsettocontroltheM2isavailableintheM2commandsusermanual
whichisfreelydownloadableonwww.audac.eu
Wire up the system
Thewiringofthesystemmustbedoneaccordingtothefollowingrules,toguarantee
properfunctioningofthesysteminallcircumstances.
1. Speakercableforamplifiedzoneoutputs:
  Minimum 2 x 1.5 mm²
If distance > 15 m: 2 x 2.5 mm²)

2. WallMountedInput&Controlunits:
DW3020/4020 UTP/FTP Cat6 cable or better
DW5065 UTP/FTP Cat6 cable or better
APM1xx UTP/FTP Cat6 cable or better

2. Musicsourcesandzoneoutputs:
Must be connected with high-quality audio cable and high-quality
connectors
3. Ethernetconnection:
  UTP/FTP Cat5e cable or better

AUDAC M2 Specifications

General

Monitor out	1
Number of Euroblock input connectors	20
Number of Euroblock output connectors	24
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
DJ mixer	No
Rack capacity	19U
Rack mounting	Yes
Channels quantity	- channels
Digital sound processing	- bit
Equalizer bands quantity	5

Weight and Dimensions

Depth	350 mm
Width	482 mm
Height	132 mm
Weight	8850 g
