Chapter 1

Connections and connectors

CONNECTION STANDARDS

Thein-andoutputconnectionsforAUDACaudioequipmentareperformedcorresponding

tointernationalwiringstandardsforprofessionalaudioequipment.

Cinch (RCA):

Forunbalancedlineinputconnections

 Tip: Signal  Sleeve:  Ground

 White: Left  Red: Right

XLR:

Forbalancedmicrophoneinputconnections

 Pin 1: Ground

 Pin 2: Signal+

 Pin 3: Signal-

3-Pin Euro-Terminal Block:

Forbalancedinandoutputconnections



 Left: Signal- (XLRPin3)

 Center:Signal+ (XLRPin2)

 Right:  Ground  (XLRPin1)

Forbalancedlineinputconnections:
