AUDAC M2 User Manual

76
Technical specifications
Inputs  Inputs 1 to 8    8 x Stereo Balanced Line / Mic with ALC
       (6-pinEuroTerminalBlock~3.81mm)  
    Frequencyrange 20Hz-20kHz
    Sensitivity  -50dBV~+10dBV
    Gainrange  50.75dB~-17.75dB+ALC
    THD+N  0.01%
    Signal/Noise  <110dB
    Impedance  10kOhm
    Equalizing  3or7Band(withadjustableQ)
    Phantompower 48VDC(2x)

  Input 9     4 x Stereo Unbalanced Line with ALC
       (4xStereoRCA)    
    Frequencyrange 20Hz-20kHz
    Sensitivity  -50dBV~+10dBV
    Gainrange  50.75dB~-17.75dB+ALC
    THD+N  0.015%
    Signal/Noise  <110dB
    Impedance  10kOhm
    Equalizing  3or7Band(withadjustableQ)

  Priority Audio    2 x Mono Balanced Line / Mic
       (3-pinEuroTerminalBlock~5.08mm)  
    Frequencyrange 20Hz-20kHz
    Sensitivity  -50dBV~+10dBV
    Gainrange  50.75dB~-17.75dB+ALC
    THD+N  0.02%
    Signal/Noise  <110dB
    Impedance  600Ohm 

  Priority Contact   2xPriorityContactInput
       (2-pinEuroTerminalBlock~5.08mm)

  General Contact   8xContactInputs
       (9-pinEuroTerminalBlock~5.08mm)

  Peripheral Interface   8xDigitalaudio/RS485/24VDC(RJ45)
       2xRS485+24VDC(RJ45)
      
  Remote Control Ethernet(RJ45)
       RS-232(D-Sub9)
  Power   IECTypeC13withfuse
Outputs Outputs 1 to 8    8xStereoBalancedLineout
       (6-pinEuroTerminalBlock~3.81mm)
  Relay outputs 1 to 8   8xRelayNO/NCoutputs
       (3-pinEuroTerminalBlock~3.81mm)

AUDAC M2 Specifications

General

Monitor out	1
Number of Euroblock input connectors	20
Number of Euroblock output connectors	24
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
DJ mixer	No
Rack capacity	19U
Rack mounting	Yes
Channels quantity	- channels
Digital sound processing	- bit
Equalizer bands quantity	5

Weight and Dimensions

Depth	350 mm
Width	482 mm
Height	132 mm
Weight	8850 g
