AUDAC M2 User Manual

3
Index
Introduction 5
M2 Block Diagram 6
Precautions 7
Safety requirements       7 
 Caution servicing       7
 EC Declaration of Conformity      7
 Waste of Electrical and Electronic Equipment (WEEE) 8
 Caution 8
Chapter 1: Connections and connectors 9
Connection standards 9
Wire up the system 11

Chapter 2: Front & rear panel 12
Front panel overview 12
Front panel description 12
Rear panel overview 13
Rear panel description 13
Chapter 3: M2 Quick start guide 16
Connecting the M2 16
Configuring the M2 17
Ready 17
Chapter 4: User interface & configuration 20
Open the user interface 20
Login screen 20
Main screen 21
Output settings 23
Configuration settings 27
Input configuration 27
Automatic Level Control (ALC) 29
3 / 7 Band Parametric EQ 31
Filters 32
Output configuration 33
Global scenes configuration 36
Timer settings 37
Paging volume 39
Priority settings 39
Peripheral configuration 41
System configuration 42
Network 42
Password 44
Time 44

AUDAC M2 Specifications

General

Monitor out	1
Number of Euroblock input connectors	20
Number of Euroblock output connectors	24
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
DJ mixer	No
Rack capacity	19U
Rack mounting	Yes
Channels quantity	- channels
Digital sound processing	- bit
Equalizer bands quantity	5

Weight and Dimensions

Depth	350 mm
Width	482 mm
Height	132 mm
Weight	8850 g
