AUDAC M2 User Manual

56
DW5065 All-in-one wall panel
Functions
TheDW5065istheadvancedAll-in-onewallpanelfortheM2.Thiswallpanelcontains
agraphicdisplayandcancontroltherouting,volume,bass,trebleandmuteformultiple
zones(upto8)ononeM2.Besidesthosecontrolfunctions,italsoprovidesthepossibility
toconnectamicrophoneandastereolineinputsource.TheDW5065wallpanelshould
beconnectedtotheM2usingUTP/FTPCat6(orbetter)cable.FirstreadthePIconnection
principlesinthebeginningofthischapterbeforemakinganyconnections.
ThefollowingfunctionsofmultiplezonesoftheM2canbecontrolled:
 -Volumewithinarangeof0dBto-70dB
 -Allinputscanbeselected
 -Mutecanbeactivated
 -Basswithinarangeof-9dBto+9dB
 -Treblewithinarangeof-9dBto+9dB
Configuration
BeforetheDW5065canoperateitshouldbeconfiguredproperly.Firstofall,anaddress
needstobeassignedandtheavailableinputsneedtobedefined.
Followthesestepstoconfigure:
1)Gotothe‘Setup’menuandclick‘Peripheralconfiguration’.Toconfigurethesettings
fortheDW5065wallpanels,clickthecorrespondingbutton.Afterthisbuttonisclicked,a
windowwillbeshownwherealltheconfigurationsettingsfortheDW5065canbemade.
Ontheleftside,adropdownlistisshownwhichallowsyoutoselecttheaddressforthe
DW5065.Theaddresscanbeselectedbetween‘W001’to‘W008’.Addressvaluestarts
atoneandisincreasedforeverysubsequentwallpanel.Afterthedesiredaddressis
selected,clickthe‘SetAddress’buttonandthedisplayontheDW5065willstartblinking.
Confirmtheaddressofthewallpanelbypushingthebigrotarybuttononthewallpanel
andtheselectedaddresswillbeassignedtothewallpanel.
2)Theoutputswhichshouldbecontrolledbythewallpanelcanbeselectedusingthe
‘Controlledoutputs’dropdownlist.Whenselectinganoutputinthisdropdownlist,the
outputnamewillappearinthelistboxbelow.Theoutputscanberemovedagainfromthis
listboxbyselectingthem,andclickingthe‘Removeoutput’button.
3)Theinputswhichareselectablewiththewallpanelcanbechoseninthe‘Selectable
inputs’dropdownlist.Aftertheinputsareclicked,theywillappearinthelistboxshown
below.Theycanberemovedagainfromthislistboxbyselectingthem,andclickingthe
‘RemoveInput’button.
Thoseselectableinputsarenotlinkedwiththe‘Quickselectionmenu’liketheinputson
theDW3020/4020.
4)CertainactionssuchasVolumeChange,Inputchange,Mute,Tonecontrolandsettings
canbedisabledfromthewallpanelbycheckingthecheckboxes.
5)Themicrophoneinputhasthepossibilitytoprovide+15Vphantompowerforpowering
condensermicrophones.ThephantompowercanbeswitchedONandOFFbyclickingthe
‘EnableMicPhantom’checkbox.ThissettingcanalsobechangedintheDW5065settings
menu.(If‘Blocksettingsmenu’isnotchecked)

AUDAC M2 Specifications

General

Monitor out	1
Number of Euroblock input connectors	20
Number of Euroblock output connectors	24
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
DJ mixer	No
Rack capacity	19U
Rack mounting	Yes
Channels quantity	- channels
Digital sound processing	- bit
Equalizer bands quantity	5

Weight and Dimensions

Depth	350 mm
Width	482 mm
Height	132 mm
Weight	8850 g
