Configuration
BeforetheDW3020/4020wallpanelscanbeused,thewallpanelsneedtobeconfigured
andassignedtooneparticularoutput.Performtheproceduredescribedbelowtomake
surethisisdonecorrectly.
Gotothe‘Setup’menuandclick‘Peripheralconfiguration’.Thenclickthe‘DW3020/4020’
button.Awindowwithadropdownlistwillbeshown,showingalltheoutputsfrom
‘Output1’to‘Output8’.Selecttheoutputtowhichthewallpanelshouldbeassigned,
andclickthe‘SetAddress’button.Theselectedoutputnumberwillstarttoblinkonthe
displayofthewallpanels,andafterpressingtheupperbuttononthedesiredwallpanel,it
willbeassignedtotheselectedzone.Simplyrepeatthisactionuntillanoutputisassigned
foreveryconnectedwallpanel.
DW3020/4020 Settings
Maximum cable length
Themaximumcablelengthdependsonthenumberofconnectedwallpanels.Whenonly
onewallpanelisconnected,amaximumcablelengthof600meterscanbereached.The
tablebelowgivesanoverviewofthemaximumcablelength,dependingontheamountof
connectedwallpanels.
No. of DW3020/4020 Wall panels Maximum cable length
1
2
3
4
5
6
7
8
600meter
600meter
400meter
300meter
200meter
150meter
120meter
100meter

AUDAC M2 Specifications

General

Monitor out	1
Number of Euroblock input connectors	20
Number of Euroblock output connectors	24
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
DJ mixer	No
Rack capacity	19U
Rack mounting	Yes
Channels quantity	- channels
Digital sound processing	- bit
Equalizer bands quantity	5

Weight and Dimensions

Depth	350 mm
Width	482 mm
Height	132 mm
Weight	8850 g
