AUXILIARY SIGNALS
Analog Sync Output LSTTL compatible signal that is intended to be
used as a trigger for stable oscilloscope
displays.
Input Monitor
Buffered version of the analog or digital input
signal. Amplitude is typically 0 – 2.83 Vpp.
Reading Monitor
Buffered version of the analog or digital analyzer
output signal after all filtering and gain stages.
Amplitude is typically 0 – 2.83 Vpp.
AUDIO MONITOR
Power Output Typically 1 watt
GENERAL / ENVIRONMENTAL
Power Requirements 100/120/230/240 Vac (-10%/+6%),
50 – 60 Hz, 60 VA max
Temperature Range
Operating 0°C to +50°C
Storage
-20°C to +60°C
Humidity
80% RH to at least +40°C (non-condensing)
Altitude
Up to 2000 meters
EMC
11
Complies with FCC subpart J - Class B
Complies with 89/336/EEC, 92/31/EEC, and
93/68/EEC.
EN 50081-1 (1992) Emissions Class B
EN 50082-1 (1992) Immunity
Safety Complies with 73/23/EEC and 93/68/EEC
EN61010-1 (1993) - IEC 1010-1 (1990) +
Amendment 1 (1992) + Amendment 2 (1995)
Installation Category II – Pollution Degree 2
Dimensions
16.5 x 6.0 x 13.6 inches [41.9 x 15.2 x 34.5 cm]
Weight
Approximately 20 lbs [9.1 kg]
Note 11 Emission and Immunity levels are influenced by the shielding performance of the
connecting cables. The shielding performance of the cable will depend on the internal
design of the cable, connector quality, and the assembly methods used. EMC
compliance was evaluated using Audio Precision XLR type cables, part number
CAB-AES.
