Audio Precision ATS-1 Access User Manual

Options Label
The Options Label (see Figure 1-5) specifies any options that are
installed in your ATS-1 Access. It is located on the lower center of the
rear panel.
The options label is filled out by the manufacturing technician when
configuring the instrument for the customer. If the IMD or EGZ options
are installed, an X will be placed in the appropriate box.
If option filters are installed, the type of filter will be marked in the
appropriate Optional Filters box.
The date of original manufacture will be written in the appropriate box.
If there are any other unique characteristics of the unit, codes will be
placed in the ‘Special’ box. These may be special modifications or
requirements from certain upgrade combinations.
Date of manufacture FW Version
Audio Measurement System
Aux 2:
Aux 1:
Optional Filters:
Installed Options:
Special
EGZ Euro. Impedances
ATS-IMD Intermod. Distortion
Figure 1-5. Options label
1 Description
Description Identification of Features and Options
ATS-1 Access User's Manual 1-9
