Audio Precision ATS-1 Access Self Test Version 3.10

Test Number and Description, Low Limit,Measured, High Limit, P/F

TEST 1.0 100 Hz FREQUENCY 99.500 Hz 99.939 Hz 100.50 Hz PASS

TEST 1.1 1 kHz FREQUENCY 995.00 Hz 999.57 Hz 1.0050kHz PASS

TEST 1.2 10 kHz FREQUENCY 9.9500kHz 10.000kHz 10.050kHz PASS

TEST 1.3 100 kHz FREQUENCY 99.500kHz 100.01kHz 100.50kHz PASS

TEST 2.0A 26.0 V AMPLITUDE 25.480 V 25.957 V 26.520 V PASS

TEST 2.0B 26.0 V AMPLITUDE 25.480 V 25.975 V 26.520 V PASS

TEST 2.1A 15.0 V AMPLITUDE 14.700 V 14.964 V 15.300 V PASS

TEST 2.1B 15.0 V AMPLITUDE 14.700 V 14.965 V 15.300 V PASS

TEST 2.2A 5.0 V AMPLITUDE 4.900 V 4.984 V 5.100 V PASS

TEST 2.2B 5.0 V AMPLITUDE 4.900 V 4.985 V 5.100 V PASS

TEST 2.3A 2.0 V AMPLITUDE 1.960 V 1.993 V 2.040 V PASS

TEST 2.3B 2.0 V AMPLITUDE 1.960 V 1.993 V 2.040 V PASS

TEST 2.4A 1.5 V AMPLITUDE 1.470 V 1.493 V 1.530 V PASS

TEST 2.4B 1.5 V AMPLITUDE 1.470 V 1.493 V 1.530 V PASS

TEST 2.5A 500 mV AMPLITUDE 490.0 mV 498.1 mV 510.0 mV PASS

TEST 2.5B 500 mV AMPLITUDE 490.0 mV 498.2 mV 510.0 mV PASS

TEST 2.6A 200 mV AMPLITUDE 196.0 mV 199.0 mV 204.0 mV PASS

TEST 2.6B 200 mV AMPLITUDE 196.0 mV 199.1 mV 204.0 mV PASS

TEST 2.7A 150 mV AMPLITUDE 147.0 mV 149.3 mV 153.0 mV PASS

TEST 2.7B 150 mV AMPLITUDE 147.0 mV 149.4 mV 153.0 mV PASS

TEST 2.8A 50 mV AMPLITUDE 49.00 mV 49.71 mV 51.00 mV PASS

TEST 2.8B 50 mV AMPLITUDE 49.00 mV 49.69 mV 51.00 mV PASS

TEST 2.9A 10 mV AMPLITUDE 9.800 mV 9.979 mV 10.20 mV PASS

TEST 2.9B 10 mV AMPLITUDE 9.800 mV 9.978 mV 10.20 mV PASS

TEST 3.0A 10 Hz FLATNESS -0.20 dB -0.02 dB 0.20 dB PASS

TEST 3.0B 10 Hz FLATNESS -0.20 dB -0.03 dB 0.20 dB PASS

TEST 3.1A 20 Hz FLATNESS -0.05 dB 0.01 dB 0.05 dB PASS

TEST 3.1B 20 Hz FLATNESS -0.05 dB 0.00 dB 0.05 dB PASS

TEST 3.2A 20 kHz FLATNESS -0.05 dB 0.01 dB 0.05 dB PASS

TEST 3.2B 20 kHz FLATNESS -0.05 dB 0.00 dB 0.05 dB PASS

TEST 3.3A 50 kHz FLATNESS -0.20 dB 0.01 dB 0.20 dB PASS

TEST 3.3B 50 kHz FLATNESS -0.20 dB 0.01 dB 0.20 dB PASS

TEST 3.4A 100 kHz FLATNESS -0.50 dB -0.01 dB 0.50 dB PASS

TEST 3.4B 100 kHz FLATNESS -0.50 dB 0.03 dB 0.50 dB PASS

TEST 3.5A 120 kHz FLATNESS -0.50 dB 0.01 dB 0.50 dB PASS

TEST 3.5B 120 kHz FLATNESS -0.50 dB 0.06 dB 0.50 dB PASS

TEST 3.6A ATTENUATOR COMP -0.05 dB -0.02 dB 0.05 dB PASS

TEST 3.6B ATTENUATOR COMP -0.05 dB -0.02 dB 0.05 dB PASS

TEST 3.7 SQUAREWAVE RESP 0.980 % 1.00 % 1.02 % PASS

2 Getting Started

Self Test Getting Started

2-6 ATS-1 Access User's Manual
