Audio Precision ATS-1 Access User Manual

some analyzer situations, other parameters may be connected to these
knobs when viewing the Main Panel. However, the knobs always
control the generator amplitude and frequency when you are viewing
the Generator Only panel. The generator operates no matter which
panel you are viewing.
The generator section of the panel will display the current amplitude,
frequency, and waveform shape.
The waveform shape is controlled by the upper left soft key on the
Generator Only panel. Waveform shapes of sine, square, and IMD (if
IMD option is installed) are available with subsequent presses of the
soft key.
The Generator Only panel also allows control of the output
configuration. Subsequent presses of the bottom center soft key permit
selection between 50 Ω Unbalanced, 50 Ω Balanced, 150 Ω Balanced,
and 600 Ω Balanced configurations.
The upper center soft key allows control of the units for analog
generator amplitude.
3 Operation
Operational Overview Controlling the Generator
ATS-1 Access User's Manual 3-13
