Speaker monitor 3-6
Holding range 4-52
Specifications D-1 - D-14
Starting sweeps 4-56
STAT (sample frequency) 4-43, 4-48
Status bits 3-20, 4-48 - 4-50
Status Bits function 4-48 - 4-50
Status Bits panel 3-20, 4-48
Stereo balance measurement 4-28
Stereo separation measurement 4-33
Stopping sweeps 4-56
Supply voltage indicators 2-1
Swapping Connector Panel and Loudspeaker
C-3 - C-5
Swapping Connector Panel and Loudspeaker
C-3 - C-5 C-2
Sweep cursors 4-56
SWEEP key 3-9, 4-53, 4-56
Sweep panel 3-9, 4-53 - 4-56
Sweep speed, tape recorder testing 5-3
Sweeping 4-53 - 4-56
Continuous (repeating) 4-56
Symbols available for setup names 4-64
Synchronizing digital generator 3-17, 3-36
T
T (total) 4-46
Table printouts 4-59
Sample 4-60
Tape recorder alignment 5-2
Tape recorder azimuth adjustments 5-2 - 5-3
Tape recorder bias adjustments 5-4
Tape recorder EQ adjustments 5-2
Tape recorder inter-head delay 5-3
Tape recorder measurements 5-2
Terminations
Analog 3-42
Digital 3-44, 4-39
THD+N
100 % reading 4-19
Changes with amplitude 4-18
Changes with frequency 4-17
Isolating sources 4-20
Selecting bandwidth 4-13
Understanding 4-11
What signal is dominant? 4-13
THD+N Function 4-7 - 4-20
Third harmonic distortion measurements 5-4
Time units 3-31 - 3-32
Time, setting 3-10
Times-10 key 3-2
Transmission link testing 5-1
Trigger Outputs 3-37
U
UI unit 3-26, 3-32
UN-WTD (Unweighted) 4-2, 4-9, 4-32
UNBAL (Unbalanced configuration) 3-43
Unbalanced vs. balanced 2-3
Units 3-26 - 3-33
Using cursors 4-56
V
V (Volts) unit 3-26 - 3-27
V in digital reading 4-50
Validity flag 3-21, 4-49
Version of internal programs 2-5
Voice announcements
reference tape 5-2
Voltage gain or loss measurement 4-28
Vp unit 3-26 - 3-27
W
W (Watts) unit 3-26, 3-30
W+F Function 4-30 - 4-32
Waveform shape
Analog 3-15
Index
Index
Index-6 ATS-1 Dual Domain User's Manual
