10.4 Debugging using Packet Recording Parameters
Packet recording parameters allow you to debug voice activity on the phone.
 To debug:
• Use the table as reference.
Table 10-3: Recording Parameters
Parameter Description
voip/packet_recording/remote_ip
The IP address (in dotted-decimal
notation) of the remote computer to
which the recorded packets are sent.
The recorded packets should be
captured by a network sniffer (such
as Wireshark).
The default value is 0.0.0.0.
voip/packet_recording/remote_port
Defines the UDP port of the remote
computer to which the recorded
packets are sent.
The valid range is 1024 to 65535.
The default value is 50000.
voip/packet_recording/enabled
Activates the packet recording
mechanism.
 0 Disable (default)

1
Enable
voip/packet_recording/rtp_recording/enabled
Only displayed if the parameter
'Enable DSP Recording' is enabled.
Activates the DSP RTP recording.
 0 Disable (default)

1
Enable
voip/packet_recording/ec_debug_recording/enabled
Activates the Echo Canceller Debug
recording.
 0 Disable (default)

1
Enable
voip/packet_recording/noise_reduction_recording/enabled
Traffic on the network stops when the
MUTE key is activated.
 0 Disable (default)
 1 Enable
voip/packet_recording/network_recording/enabled
Activates the DSP network (TDM
Out) recording.
 0 Disable (default)
 1 Enable
voip/packet_recording/tdm_recording/enabled
Activates the DSP TDM (TDM In)
recording.
 0 Disable (default)

1
Enable
voip/packet_recording/cng_debug_recording/enabled
Default=0
