400HD Series IP Phones
Administrator's Manual 38 Document #: LTRT-11973
Figure 3-11: Predefined Options and Values – Add OVOC Server Location
Note: Make sure you defined in the enterprise's DHCP server http://<OVOC server IP
address>/firmwarefiles;ipp/dhcpoption160.cfg for DHCP Option 160.
10. Decide if the DHCP Scope Option needs to be assigned to phones in a specific VLAN
(Scope), or to the entire server (acrtplab-ad.audiocodes.local) for IPv4 addresses.
VLAN Scope
11. Assign to a specific VLAN (Scope of IP addresses such as the Scope below 172.17.0.0,
or to multiple Scopes, to be performed separately on each Scope).
a. If selecting a VLAN, expand the 'Scope Leased' folder, select 'Scope Options',
and then select Configure Options from the popup menu.
Figure 3-12: 'Scope Leased' Folder - Configure Options
