Administrator's Manual 4. Configuring Networking

Version 3.4.3 55 400HD Series IP Phones

4.3 Configuring LAN and PC Port Settings

Port settings can be configured.

 To define the phone's port settings:

• Use the table as reference.

Table 4-7: Port Settings

Parameter Description

network/lan/port_mode Sets the LAN port mode.

Valid values are:

AUTOMATIC = Auto negotiation.

FULL_10 = 10Mbps + full duplex

FULL_100 = 100Mbps + half duplex

HALF_10 = 10Mbps + full duplex

HALF_100 = 100Mbps + half duplex

FULL _ 1Gbps = 1 Gbit/s port + full duplex

network/pc/port_mode Sets the computer port mode.

Valid values are:

AUTOMATIC = Auto negotiation

FULL_10 = 10Mbps + full duplex

FULL_100 = 100Mbps + half duplex

HALF_10 = 10Mbps + full duplex

HALF_100 = 100Mbps + half duplex

DISABLE = Disables the PC port mode
