Version 7.2 1029 Mediant 1000B Gateway & E-SBC
User's Manual 62. Configuration Parameters Reference
Parameter Description

[1] Enable = No Randomize
Gateway RTCP XR Report Mode
configure voip > sip-definition
settings > rtcp-xr-rep-mode
[RTCPXRReportMode]
Enables the device to send RTCP XR in SIP PUBLISH
messages and defines the interval at which they are sent.
 [0] Disable = (Default) RTCP XR is not sent.
 [1] End Call = RTCP XR is sent at the end of the call.
 [2] End Call & Periodic = RTCP XR is sent at the end of the
call and periodically according to the RTCPInterval
parameter.
 [3] End Call & End Segment = RTCP XR is sent at the end
of the call and at the end of each media segment of the
call. A media segment is a change in media, for example,
when the coder is changed or when the caller toggles
between two called parties (using call hold/retrieve). The
RTCP XR sent at the end of a media segment contains
information only of that segment. If the segment does not
contain RTP/RTCP content, the RTCP XR is not sent. For
call hold, the device sends an RTCP XR each time the call
is placed on hold and each time it is retrieved. In addition,
the Start timestamp in the RTCP XR indicates the start of
the media segment; the End timestamp indicates the time
of the last sent periodic RTCP XR (typically, up to 5
seconds before reported segment ends).
Note: The parameter is applicable only to the Gateway
application.
publication-ip-group-id
[PublicationIPGroupID]
Defines the IP Group to where the RTCP XR is sent.
SBC RTCP XR Report Mode
configure voip > sip-definition
settings > sbc-rtcpxr-report-mode
[SBCRtcpXrReportMode]
Enables the sending of RTCP XR reports of QoE metrics at
the end of each call session (i.e., after a SIP BYE). The RTCP
XR is sent in the SIP PUBLISH message.
 [0] Disable (default)
 [1] End of Call
Note: The parameter is applicable only to the SBC application.
62.10 Gateway Application Parameters
62.10.1 Fax and Modem Parameters
The fax and modem parameters are described in the table below.
Table 62-38: Fax and Modem Parameters
Parameter Description
Fax Transport Mode
configure voip > media fax-
modem > fax-transport-mode
Determines the fax transport mode used by the device.
 [0] Disable = transparent mode
 [1] T.38 Relay (default)
