Version 7.2 49 Mediant 1000B Gateway & E-SBC
User's Manual 6. Web-Based Management
Note:
• The default login username and password is "Admin" (case-sensitive). To change
the login credentials, see ''Configuring Management User Accounts'' on page 65.
• By default, Web access is only through the IP address of the OAMP interface.
However, you can allow access from all of the device's IP network interfaces, by
setting the EnableWebAccessFromAllInterfaces parameter to 1.
• By default, autocompletion of the login username is enabled whereby the
'Username' field offers previously entered usernames. To disable autocompletion,
use the WebLoginBlockAutoComplete ini file parameter.
• Depending on your Web browser's settings, a security warning box may be
displayed. The reason for this is that the device's certificate is not trusted by your
PC. The browser may allow you to install the certificate, thus skipping the warning
box the next time you connect to the device. If you are using Windows Internet
Explorer, click View Certificate, and then Install Certificate. The browser also
warns you if the host name used in the URL is not identical to the one listed in the
certificate. To resolve this, add the IP address and host name (ACL_nnnnnn,
where nnnnnn is the serial number of the device) to your hosts file, located at
/etc/hosts on UNIX or C:\Windows\System32\Drivers\ETC\hosts on Windows; then
use the host name in the URL (e.g., https://ACL_280152). Below is an example of
a host file:
127.0.0.1 localhost
10.31.4.47 ACL_280152
6.1.3 Areas of the GUI
The areas of the Web interface's GUI are shown in the figure below and described in the
subsequent table.
Figure 6-2: Main Areas of the Web Interface GUI
Table 6-1: Description of the Web GUI Areas
Item # Description
