User's Manual 24. Manipulation
Parameter Description
Plans and Type of Number on page 529.
NPI
npi
[NumberPlan]
Defines the Numbering Plan Indicator (NPI).
 [-1] = Not configured and the value received from PSTN/IP is used.
 [0] Unknown (default)
 [1] E.164 Public
 [9] Private
Note:
 The parameter is applicable only to the Destination Phone Number
Manipulation for IP-to-Tel Calls table and Source Phone Number
Manipulation for IP-to-Tel Calls table.
 NPI can be used in the SIP Remote-Party-ID header by using the
EnableRPIHeader and AddTON2RPI parameters.
 For more information on available NPI/TON values, see Numbering
Plans and Type of Number on page 529.
Presentation
is-presentation-restricted
[IsPresentationRestricted]
Enables caller ID.
 Not Configured = Privacy is determined according to the Caller ID
table (see Configuring Caller Display Information on page 582).
 [0] Allowed = Sends Caller ID information when a call is made using
these destination/source prefixes.
 [1] Restricted = Restricts Caller ID information for these prefixes.
Note:
 The parameter is applicable only to the Source Phone Number
Manipulation for IP-to-Tel Calls table and Source Phone Number
Manipulation for Tel-to-IP Calls table.
 If you configure the parameter to Restricted and the 'Asserted
Identity Mode' (AssertedIdMode) parameter to Add P-Asserted-
Identity, the From header in the INVITE message includes the
following:
From: 'anonymous' <sip:
anonymous@anonymous.invalid> and 'privacy: id'
header
24.3 Manipulating Number Prefix
The device supports a notation for adding a prefix where part of the prefix is first extracted
from a user-defined location in the original destination or source number. The notation is
entered in the 'Prefix to Add' field in the Number Manipulation tables (see ''Configuring
Source/Destination Number Manipulation'' on page 503): x[n,l]y...
where,

x = any number of characters/digits to add at the beginning of the number (i.e. first
digits in the prefix).

[n,l] = defines the location in the original destination or source number where the digits
y are added:
• n = location (number of digits counted from the left of the number) of a specific
string in the original destination or source number.
• l = number of digits that this string includes.

y = prefix to add at the specified location.
