User's Manual 222 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
To enable RADIUS:
1. Open the Authentication Server page (Setup menu > Administration tab > Web &
CLI folder > Authentication Server).
Figure 15-6: Enabling RADIUS
2. Under the RADIUS group, from the 'Enable RADIUS Access Control' drop-down list,
select Enable.
3. Click Apply, and then reset the device with a save-to-flash for your settings to take
effect.
15.2.2 Configuring RADIUS Servers
The RADIUS Servers table lets you configure up to three RADIUS servers. You can use
RADIUS servers for RADIUS-based management-user login authentication and/or
RADIUS-based accounting (sending of SIP CDRs to the RADIUS server).
When multiple RADIUS servers are configured, RADIUS server redundancy can be
implemented. When the primary RADIUS server is down, the device sends a RADIUS
request twice (one retransmission) and if both fail (i.e., no response), the device considers
the server as down and attempts to send requests to the next server. The device continues
sending RADIUS requests to the redundant RADIUS server even if the primary server
returns to service later on. However, if a device reset occurs, the device sends RADIUS
requests to the primary RADIUS server. By default, the device waits for up to two seconds
(i.e., timeout) for a response from the RADIUS server for RADIUS requests and
retransmission before it considers the server as down.
For each RADIUS server, the IP address, port, and shared secret can be configured. Each
RADIUS server can be defined for RADIUS-based login authentication and/or RADIUS-
based accounting. By setting the relevant port (authentication or accounting) to "0" disables
the corresponding functionality. If both ports are configured, the RADIUS server is used for
authentication and accounting. All servers configured with non-zero Authorization ports
form an Authorization redundancy group and the device sends authorization requests to
one of them, depending on their availability. All servers configured with non-zero
Accounting ports form an Accounting redundancy group and the device sends accounting
CDRs to one of them, depending on their availability. Below are example configurations:
Only one RADIUS server is configured and used for authorization and accounting
purposes (no redundancy). Therefore, both the Authorization and Accounting ports are
defined.
Three RADIUS servers are configured:
• Two servers are used for authorization purposes only, providing redundancy.
Therefore, only the Authorization ports are defined, while the Accounting ports
are set to 0.
• One server is used for accounting purposes only (i.e., no redundancy). Therefore,
only the Accounting port is defined, while the Authorization port is set to 0.
Two RADIUS servers are configured and used for authorization and accounting
purposes, providing redundancy. Therefore, both the Authorization and Accounting
ports are defined.
The status of the RADIUS severs can be viewed through CLI:
# show system radius servers status
The example below shows the status of two RADIUS servers in redundancy mode for
authorization and accounting:
