Version 7.2 1193 Mediant 1000B Gateway & E-SBC
User's Manual 64. Technical Specifications
Function Specification
Redundancy
Detection of proxy failures and subsequent routing to alternative
proxies
Routing Features
Least-cost routing, call forking, load balancing, E911 gateway
support, emergency call detection and prioritization
Management
OAM&P
Browser-based GUI, CLI, SNMP, EMS, INI Configuration file, REST
API
OSN Server Platform (Optional)
Single Chassis Integration
Embedded, Partner Application Platform for third-party services
Memory
Up to 8 GB RAM
Storage
HDD or SDD
Physical / Environmental
Dimensions
1U x 320 mm x 345 mm (HxWxD)
Weight
Approx. 5.95lb (2.7kg) installed with OSN
Mounting
Desktop or 19" mount
Power
Single universal power supply 100-240 VAC, 50-60 Hz, 1.5A max. or
optional redundant power supply
Environmental
 Operational: 0 to 40°C (32 to 104°F)
 Storage: -20 to 70°C (-4 to 158°F)
 Relative Humidity: 10 to 85% non-condensing
