User's Manual 136 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
(Optional) Primary and secondary domain name server (DNS) addresses for resolving
FQDNs into IP addresses.
Ethernet Device: Layer-2 bridging device and assigned a VLAN ID. As the Ethernet
Device is associated with an Ethernet Group, this is useful for setting trusted and un-
trusted networks on different physical Ethernet ports. Multiple entries in the IP
Interfaces table may be associated with the same Ethernet Device, providing multi-
homing IP configuration (i.e., multiple IP addresses on the same interface/VLAN).
Complementing the IP Interfaces table is the Static Routes table, which lets you configure
static routing rules for non-local hosts/subnets. For more information, see ''Configuring
Static IP Routing'' on page 142.
Note:
• Before configuring IP interfaces, it is recommended that you read the IP interface
configuration guidelines in ''IP Interfaces Table Configuration Guidelines'' on page
139.
The following procedure describes how to configure IP network interfaces through the Web
interface. You can also configure it through ini file (InterfaceTable) or CLI (configure
network > interface network-if).
To configure IP network interfaces:
1. Open the IP Interfaces table (Setup menu > IP Network tab > Core Entities folder >
IP Interfaces).
2. Click New; the following dialog box appears:
Figure 12-3: IP Interfaces Table - Dialog Box
3. Configure the IP network interface according to the parameters described in the table
below.
4. Click Apply.
