User's Manual 158 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
Note: The device first attempts to resolve a domain name using the table. If the
domain is not configured in the table, the device performs a Service Record (SRV)
resolution using an external DNS server, configured in the IP Interfaces table (see
''Configuring IP Network Interfaces'' on page 135).
The following procedure describes how to configure the Internal SRV table through the
Web interface. You can also configure it through ini file (SRV2IP) or CLI (configure network
> dns srv2ip).
 To configure the device's SRV table:
1. Open the Internal SRV table (Setup menu > IP Network tab > DNS folder > Internal
SRV).
2. Click New; the following dialog box appears:
Figure 12-15: Internal SRV Table - Add Dialog Box
3. Configure an SRV rule according to the parameters described in the table below.
4. Click Apply, and then save your settings to flash memory.
Table 12-20: Internal SRV Table Parameter Descriptions
Parameter Description
General
Index Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Domain Name
domain-name
[Srv2Ip_InternalDomain]
Defines the host name to be translated.
The valid value is a string of up to 31 characters. By default, no
value is defined.
Transport Type
transport-type
[Srv2Ip_TransportType]
Defines the transport type.
 [0] UDP (default)
 [1] TCP
 [2] TLS
To Next Page
