User's Manual 300 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
Parameter Description
[QOEProfile_SensitivityLevel]

[1] Low = Pre-configured low sensitivity thresholds.
 [2] Medium = (Default) Pre-configured medium sensitivity
thresholds.
 [3] High = Pre-configured high sensitivity thresholds.
Reporting is done for small fluctuations in parameter values.
5. In the Quality of Experience Profile table, select the row for which you want to
configure QoE thresholds, and then click the Quality of Experience Color Rules link
located below the table; the Quality of Experience Color Rules table appears.
6. Click New; the following dialog box appears:
Figure 16-4: Quality of Experience Color Rules Table - Dialog Box
7. Configure a rule according to the parameters described in the table below.
8. Click New, and then save your settings to flash memory.
Table 16-3: Quality of Experience Color Rules Table Parameter Descriptions
Parameter Description
General
Index
index
[QOEColorRules_ColorRuleIndex]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Monitored Parameter
monitored-parameter
[QOEColorRules_monitoredParam]
Defines the parameter to monitor and report.
 [0] MOS (default)
 [1] Delay
 [2] Packet Loss
 [3] Jitter
 [4] RERL [Echo]
Direction
direction
[QOEColorRules_direction]
Defines the monitoring direction.
 [0] Device Side (default)
 [1] Remote Side
Sensitivity Level
sensitivity-level
[QOEColorRules_profile]
Defines the sensitivity level of the thresholds.
 [0] User Defined = Need to define the thresholds in the
parameters described below.
 [1] Low = Pre-configured low sensitivity threshold values.
Thus, reporting is done only if changes in parameters' values
