User's Manual 304 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
The following procedure describes how to configure Bandwidth Profiles through the Web
interface. You can also configure it through ini file (BWProfile) or CLI (configure voip > qoe
bw-profile).
 To configure a Bandwidth Profile:
1. Open the Bandwidth Profile table (Setup menu > Signaling & Media tab > Media
folder > Quality of Experience > Bandwidth Profile).
2. Click New; the following dialog box appears:
Figure 16-6: Bandwidth Profile Table - Dialog Box
3. Configure a rule according to the parameters described in the table below.
4. Click Apply, and then reset the device with a save to flash memory.
Table 16-5: Bandwidth Profile Table Parameter Descriptions
Parameter Description
General
Index
[BWProfile_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
name
[BWProfile_Name]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 20 characters.
Egress Audio Bandwidth
egress-audio-bandwidth
[BWProfile_EgressAudioBandwidth]
Defines the major (total) threshold for outgoing audio traffic (in
Kbps).
Ingress Audio Bandwidth
ingress-audio-bandwidth
[BWProfile_IngressAudioBandwidth]
Defines the major (total) threshold for incoming audio traffic (in
Kbps).
Egress Video Bandwidth
egress-video-bandwidth
[BWProfile_EgressVideoBandwidth]
Defines the major (total) threshold for outgoing video traffic (in
Kbps).
