AudioCodes MSBG Series User Manual

Version 7.2 349 Mediant 1000B Gateway & E-SBC
User's Manual 17. Control Network
Parameter Description

To configure SRDs, see Configuring SRDs on page 317.
General
Index
configure voip > voip-network
proxy-set
[ProxySet_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
proxy-name
[ProxySet_ProxyName]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 20 characters.
Note: Each row must be configured with a unique name.
Gateway IPv4 SIP Interface
gwipv4-sip-int-name
[ProxySet_GWIPv4SIPInterface
Name]
Assigns an IPv4-
based SIP Interface for Gateway calls to the Proxy
Set.
Note:
 At least one SIP Interface must be assigned to the Proxy Set.
 The parameter appears only if you have configured a network
interface with an IPv4 address in the IP Interfaces table (see
Configuring IP Network Interfaces on page 135).
 To configure SIP Interfaces, see Configuring SIP Interfaces on
page 326.
SBC IPv4 SIP Interface
sbcipv4-sip-int-name
[ProxySet_SBCIPv4SIPInterfac
eName]
Assigns an IPv4-based SIP Interface for SBC calls to the Proxy
Set.
Note:
 At least one SIP Interface must be assigned to the Proxy Set.
 The parameter appears only if you have configured a network
interface with an IPv4 address in the IP Interfaces table (see
Configuring IP Network Interfaces on page 135).
 To configure SIP Interfaces, see ''Configuring SIP Interfaces''
on
page 326.
Gateway IPv6 SIP Interface
gwipv6-sip-int-name
[ProxySet_GWIPv6SIPInterface
Name]
Assigns an IPv6-
based SIP Interface for Gateway calls to the Proxy
Set.
Note:
 At least one SIP Interface must be assigned to the Proxy Set.
 The parameter appears only if you have configured a network
interface with an IPv6 address in the IP Interfaces table.
SBC IPv6 SIP Interface
sbcipv6-sip-int-name
[ProxySet_SBCIPv6SIPInterfac
eName]
Assigns an IPv6-based SIP Interface for SBC calls to the Proxy
Set.
Note:
 At least one SIP Interface must be assigned to the Proxy Set.
 The parameter appears only if you have configured a network
interface with an IPv6 address in the IP Interfaces table.
TLS Context Index
tls-context-index
[ProxySet_TLSContextName]
Assigns a TLS Context (SSL/TLS certificate) to the Proxy Set.
By default, no TLS Context is assigned. If you assign a TLS
Context, the TLS Context is used as follows:
 Incoming calls: If the 'Transport Type' parameter (in this table)
is set to TLS and the incoming call is successfully classified to
an IP Group based on the Proxy Set, this TLS Context is used.
If the 'Transport Type' parameter is set to UDP or classification
