User's Manual 354 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
Parameter Description
Note: An SRV query can return up to four host names. For each
host name, the subsequent DNS A-record query can resolve into
up to 15 IP addresses. However, the device supports up to 30
DNS-resolved IP addresses. If the device receives more than this
number of IP addresses, it uses the first 30 IP addresses in the
received list and ignores the rest.
Proxy Address Table
Index
proxy-ip-index
[ProxyIp_ProxyIpIndex]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Proxy Address
proxy-address
[ProxyIp_IpAddress]
Defines the address of the proxy.
Up to 10 addresses can be configured per Proxy Set. The address
can be defined as an IP address in dotted-decimal notation (e.g.,
201.10.8.1) or FQDN. You can also specify the port using the
following format:
 IPv4 address: <IP address>:<port> (e.g., 201.10.8.1:5060)
 IPv6 address: <[IPV6 address]>:<port> (e.g.,
[2000::1:200:200:86:14]:5060)
Note:
For the SBC application: You can configure the device to use
the port indicated in the Request-URI of the incoming message,
instead of the port configured for the parameter. To enable this,
use the IPGroup_SBCRouteUsingRequestURIPort parameter for
the IP Group that is associated with the Proxy Set (Configuring IP
Groups on page
333).
Transport Type
transport-type
[ProxyIp_TransportType]
Defines the transport type for communicating with the proxy.
 [0] UDP
 [1] TCP
 [2] TLS
 [-1] = (Default) The transport type is according to the settings of
the global parameter, SIPTransportType.
