Version 7.2 375 Mediant 1000B Gateway & E-SBC
User's Manual 18. SIP Definitions
Manipulation folder > Message Policies).
2. Click New; the following dialog box appears:
Figure 18-5: Message Policies Table - Add Dialog Box
3. Configure a Message Policy rule according to the parameters described in the table
below.
4. Click Apply.
Table 18-3: Message Policies Table Parameter Descriptions
Parameter Description
General
Index
[MessagePolicy_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique
index.
Name
name
[MessagePolicy_Name]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 20 characters.
Note: Each row must be configured with a unique
name.
Limits
Max Message Length
max-message-length
[MessagePolicy_MaxMessageLength]
Defines the maximum SIP message length.
The valid value is up to 32,768 characters. The default
is 32,768.
Max Header Length
max-header-length
[MessagePolicy_MaxHeaderLength]
Defines the maximum SIP header length.
The valid value is up to 512 characters. The default is
512.
Max Body Length Defines the maximum SIP message body length. This
