AudioCodes MSBG Series User Manual

User's Manual 426 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
Parameter Description
originating fax. However, this mode is not recommended.
Note: The corresponding global parameter is CNGDetectorMode.
Vxx Modem Transport Type
vxx-transport-type
[IpProfile_VxxTransportType]
Defines the modem transport type.
 [-1] = (Not Configured) The settings of the global parameters are
used:

V21ModemTransportType

V22ModemTransportType

V23ModemTransportType

V32ModemTransportType

V34ModemTransportType
 [0] Disable = Transparent.
 [2] Enable Bypass (Default)
 [3] Events Only = Transparent with Events.
For a detailed description of the parameter per modem type, see the
relevant global parameter (listed above).
NSE Mode
nse-mode
[IpProfile_NSEMode]
Enables Cisco's compatible fax and modem bypass mode, Named
Signaling Event (NSE) packets.
 [0] Disable (Default)
 [1] Enable
In NSE bypass mode, the device starts using G.711 A-Law (default)
or G.711 -Law, according to the FaxModemBypassCoderType
parameter. The payload type for these G.711 coders is a standard
one (8 for G.711 A-Law and 0 for G.711 -Law). The parameters
defining payload type for the 'old' Bypass mode
FaxBypassPayloadType and ModemBypassPayloadType are not
used with NSE Bypass. The bypass packet interval is configured
according to the FaxModemBypassBasicRtpPacketInterval
parameter.
The SDP contains the following line:
'a=rtpmap:100 X-NSE/8000'.
Note:
 When enabled, the following conditions must also be met:

The Cisco gateway must include the following definition:
'modem passthrough nse payload-type 100 codec g711alaw'.

Set the Modem transport type to Bypass mode
(VxxModemTransportType is set to 2) for all modems.

Set the NSEPayloadType parameter to 100.
 The corresponding global parameter is NSEMode.
Gateway Answering Machine
AMD Mode
amd-mode
[IpProfile_AmdMode]
Enables the device to disconnect the IP-to-Tel call upon detection of
an answering machine on the Tel side.
 [0] Don't Disconnect = (Default) Device does not disconnect call
upon detection of an answering machine.
 [1] Disconnect on AMD = Device disconnects call upon detection
of an answering machine. It disconnects the call only after receipt
of an ISDN Connect from the Tel side. In such a scenario, the
device sends a SIP BYE message upon AMD.
Note:
 When the parameter is set to Disconnect on AMD [1]), the feature
